Originally published on VONNG.

GitHub Release | Release Note

Pigsty v1.3 is officially released, featuring Redis support, a rebuilt PGCAT application, and enhanced PGSQL monitoring.

---

Redis Support

While PostgreSQL is the world’s most advanced open-source relational database, every hero needs a sidekick. Pigsty v1.3 introduces a powerful caching companion for PostgreSQL: the world’s fastest database — Redis.

Redis delivers incredible performance, easily hitting 200-300k QPS on a single core.

The Pigsty demo now includes Redis cluster examples:

Three Deployment Modes

Redis has three classic deployment patterns: primary-replica (Standalone), native cluster (Cluster), and high-availability sentinel (Sentinel). Pigsty v1.3 supports all three.

The Redis Overview dashboard shows three sample clusters, each demonstrating a different deployment mode.

Declarative Configuration

Defining a Redis cluster works the same way as PostgreSQL. After declaring your config, just run redis.yml -l <cluster> to create the cluster:

A Redis cluster only needs a few required identity parameters. Of course, you can use additional parameters for fine-grained configuration:

Auto-Monitoring

Redis clusters and instances created with Pigsty are automatically integrated into the monitoring system.

The Redis cluster dashboard homepage — click on a specific instance to jump to instance-level monitoring:

---

PGCAT Overhaul

v1.3 rebuilds the PGCAT application — a tool for browsing and visualizing PostgreSQL system catalogs directly from Grafana.

Single PostgreSQL instance catalog info: databases, active sessions, running queries.

More instance-level catalog info: configuration, replication, memory usage, persistence, roles.

Single PostgreSQL database catalog info, including schemas, tables, indexes, sequences, and other objects.

Redesigned PGCAT TABLE dashboard with detailed per-column statistics.

Agentless Design

PGCAT only needs a target database URL — no agent installation required. Even monitor-only deployments of existing instances get full PGCAT functionality.

In Pigsty v1.3’s monitor-only deployment mode, external PostgreSQL instances are also registered in Grafana with PGCAT enabled by default.

---

PGSQL Enhancements

The core PGSQL monitoring application also received significant improvements.

In Pigsty v1.3, the PGSQL Cluster dashboard adds quick-navigation panels for 10 key metrics.

Both PGSQL Instance and PGSQL Cluster now include quick-navigation panels for rapid problem identification. PGSQL Service was completely redesigned — simpler and more intuitive for quickly understanding cluster topology. Other dashboards also received optimizations and improvements.

Additionally, v1.3 includes improvements to the semi-automated database migration playbook and profiling tool support.

---

v1.3.0 Release Notes

Redis Support

PGCAT Overhaul

PGSQL Enhancements

Monitor Deployment

• Grafana datasources auto-register during monitor-only deployment

Software Upgrades

• PostgreSQL 13 added to default package list
• PostgreSQL upgraded to 14.1 as default
• Added Greenplum RPM packages and dependencies
• Added Redis RPM and source packages
• Added perf as default package

---

v1.3.1 Release Notes

Monitoring

• PGSQL & PGCAT dashboard improvements
• Optimized PGCAT Instance & PGCAT Database layout
• Added key metric panels to PGSQL Instance dashboard (consistent with PGSQL Cluster)
• Added table/index bloat panels to PGCAT Database, removed PGCAT Bloat dashboard
• Added index information to PGCAT Database dashboard
• Fixed broken panels in Grafana 8.3
• Added Redis index to Nginx homepage

Deployment

• New infra-demo.yml playbook for one-click bootstrap
• New infra-jupyter.yml playbook for optional JupyterLab server
• New infra-pgweb.yml playbook for optional PGWeb server
• Added pg alias on meta node for starting PostgreSQL cluster from admin user
• Adjusted max_locks_per_transactions in all Patroni config templates per timescaledb-tune recommendations
• Added citus.node_conninfo: 'sslmode=prefer' to config templates for SSL-free Citus usage
• Added all extensions (except pgrouting) from PGDG14 to package list
• Upgraded node_exporter to v1.3.1
• Added PostgREST v9.0.0 for generating REST APIs from PostgreSQL schemas

Bug Fixes

• Grafana security vulnerability fix (upgraded to v8.3.1, details)
• Fixed pg_instance & pg_service issues in register role when starting playbook mid-run
• Fixed Nginx homepage rendering on hosts without pg_cluster variable
• Fixed style issues when upgrading to Grafana 8.3.1
